Description
The ZAMTAS NG Series is a next-generation automatic sliding door system for framed and frameless glass entrances. Its slim, roughly 130 mm transom houses a DC motor with optical encoder and closed-loop control, keeping the drive discreet in modern interiors. MEK Uganda supplies the NG Series for offices, retail and architectural projects.
Key Features
- Low-profile track height of approximately 130 mm
- Full electric DC motor in a compact extruded aluminium transom
- Compatible with framed and frameless glass doors
- Microprocessor control with optical sensors and safety monitoring
- Interfaces with access control, security and building management systems
- Battery backup and anti-panic functions available
- Single sliding, bi-parting and telescopic configurations
Technical Specifications
- Total height of tracks/outer housing: Approximately 130 mm (approx. 132 mm)
- Cross-section of housing: Approximately 132 mm (H) × 155 mm (W)
- Maximum weight of door leaf: Up to approximately 120 kg per leaf (model dependent)
- Clear opening width (single leaf): Configurable; up to approximately 3,000 mm
- Drive system: DC motor with optical encoder and closed-loop control
- Control system: Microprocessor controller with programmable modes and BMS/security interfaces
- Safety functions: Anti-pinch, anti-collision, safety stop, and reverse
- Backup power: Battery backup and anti-panic available during power failure
- Operating temperature: Suitable for standard automatic door conditions
- Standards: Meets relevant automatic door safety and performance standards (e.g., AS, EN)
Applications
- Office buildings and corporate lobbies
- Shopping centres and retail entrances
- Hotels and architectural glass façades
- Banks and buildings with BMS or security integration
Frequently Asked Questions
Does the NG Series work with frameless glass?
Yes. It is designed for both framed and frameless glass sliding doors.
What door layouts are available?
The NG Series can be configured as single sliding, bi-parting or telescopic systems.
Is pricing available online?
Pricing depends on door size, configuration and accessories. Contact MEK Uganda for a quotation tailored to your opening.
To request a quotation or technical consultation, contact MEK Uganda at sales@mek.co.ug.
