Description
The Hermetic AutoDoor is an automatic sliding door that closes with an airtight seal, designed for operating theatres, ICUs, isolation rooms and clean corridors. A patented track and sealing frame achieve Class 4 air tightness, which helps control airflow, reduce cross-contamination and lower HVAC load. MEK Uganda offers it to hospitals and medical facilities that need hygienic, barrier-free access.
Key Features
- Patented sealing technology with Class 4 air tightness, certified to TÜV EN 12207
- Operator and door sit flush with the wall
- Emergency lever handle reduces opening force during power outages
- Quiet running with good sound insulation
- Barrier-free access for patients, staff and equipment
- Control unit meets medical electrical safety standards, with several configurable control options
- Steel construction with hermetic sealing frame and brush system
Technical Specifications
- Opening width (single panel): Up to 3000 mm
- Maximum door leaf weight, single leaf: Up to 500 kg
- Maximum door leaf weight, double leaf: Up to 2 × 100 kg
- Maximum opening height: Up to 3000 mm
- Operator height: 180 mm
- Operator depth: 117 mm
- Opening speed: Adjustable, 0.1 – 0.4 m/s
- Closing speed: Adjustable, 0.1 – 0.4 m/s
- Hold-open time: 0 – 30 seconds
- Ambient operating temperature: -15°C to +50°C
- Protection class: IP20
- Maximum power consumption: 250 W
- Safety sensor test signal compatibility: Yes
- Forced limitation adjustable (DIN 18650 & EN 16005): Yes
- Floor guides: Reinforced plastic
- Sealing frame: Aluminium
Applications
- Hospital operating theatres and ICUs
- Isolation rooms and clean corridors
- Medical facilities and clinics with controlled-air rooms
- Dry rooms and other hygiene-critical spaces
Frequently Asked Questions
How airtight is the Hermetic AutoDoor?
Its patented sealing system achieves Class 4 air tightness, certified to TÜV EN 12207.
Can the door be opened during a power failure?
Yes. An emergency lever handle reduces the force needed to open the door manually when power is lost.
Is pricing available online?
Pricing depends on door size, configuration and accessories. Contact MEK Uganda for a quotation tailored to your opening.
To request a quotation or technical consultation, contact MEK Uganda at sales@mek.co.ug.
