Description
The UL Listed Fire Rated Steel Door is a UL-labelled steel door and frame assembly that compartmentalises fire in commercial and industrial buildings. Assemblies conform to UL 10C, which includes a fire endurance test followed by a hose stream test, and door labels range from 20 minutes to 3 hours. MEK Uganda supplies single doors, double egress doors and matching frames.
Key Features
- UL-labelled doors in 3-hour, 1½-hour, 45-minute and 20-minute ratings
- Matching UL-rated frames, plus sidelight, borrowed-light and transom frames
- Double egress door configurations available
- Galvanised steel leaf and frame for corrosion resistance and long service life
- Honeycomb or treated wool insulation infill
- Fire-rated glazing up to 3 hours
- Smooth, reliable operation with in-house powder-coated finish
Technical Specifications
- Door ratings: 3 hours, 1½ hours, 45 min. and 20 min. labels
- Frame ratings: 3 hour and 1½-hour
- Sidelight, borrowed-light and transom frames: 45 min. and 20 min. labels
- Frame: 1.6 mm galvanised steel
- Door leaf: 1.2 mm galvanised steel
- Door leaf thickness: 45 mm – 49 mm
- Infill insulation: Honeycomb / treated wool insulation
- Fire-rated glass: Up to 3 hours rating
- Double leaf: 2250 × 2400 mm, frame section 154 × 77 mm, double-rebated
- Single leaf: 1200 × 2400 mm, frame section 150 × 67 mm, double-rebated
- Standard: UL 10C (fire endurance test followed by hose stream test)
Applications
- Factories, textile mills and pharmaceutical plants
- Hospitals and healthcare facilities
- Hotels and commercial buildings
- Airports
- Power plants
Frequently Asked Questions
What does UL listed mean for a fire door?
It means the door and frame assembly carries a UL label for its fire rating. MEK’s UL listed assemblies conform to UL 10C, which combines a fire endurance test with a hose stream test.
What fire ratings are available?
Doors are labelled for 3 hours, 1½ hours, 45 minutes and 20 minutes; frames for 3 hours and 1½ hours; and sidelight, borrowed-light and transom frames for 45 and 20 minutes.
How much does the UL Listed Fire Rated Steel Door cost in Uganda?
Pricing depends on size, fire rating and hardware. Contact MEK Uganda for a quotation based on your opening schedule.
To request a quotation or technical consultation, contact MEK Uganda at sales@mek.co.ug.
