Description
The MEK-SW06 AutoSwing Turnstile is a compact swing-barrier turnstile that controls pedestrian access with RFID cards, barcodes, fingerprints or facial recognition. Its SUS304 stainless steel cabinet, acrylic glass barriers and brushless DC motor are built for long service in indoor and outdoor lanes. MEK Uganda supplies it for schools, offices, gyms and residential communities.
Key Features
- SUS304 stainless steel cabinet with smooth finish and no exposed screws
- Supports RFID, barcode, fingerprint and facial recognition; communicates over TCP/IP or RS-485
- MEK-SW06 Plus series comes pre-integrated with a card or fingerprint reader of the customer’s choice
- Barriers stay locked until a valid credential is presented, then swing open
- Single-lane and dual-lane models
- Each unit and reader factory tested; plug-and-play installation
- Emergency mode
Technical Specifications
- Power requirements: AC 100-120V / 200-240V, 50/60Hz
- Operating temperature: -28°C to +60°C
- Humidity tolerance: 20% to 95% (non-condensing)
- Environment: Indoor and outdoor use
- Throughput speed: RFID: Up to 30 users per minute; Fingerprint: Up to 25 users per minute
- Lane width: 550-950mm
- Dimensions (mm): L=1200/1400, W=280, H=980
- Packed dimensions (mm): L=1400/1500, W=400, H=1000
- Net weight: 90kg
- Weight with packing: 109kg
- Cabinet material: SUS304 stainless steel
- Barrier material: Acrylic glass
- Barrier movement: Swing
- Emergency mode: Yes
- Motor: DC brush-less motor
- MCBF (Mean Cycles Between Failure): 5 million
Applications
- Schools and universities
- Corporate offices and banks
- Gyms and fitness centres
- Residential estates and gated communities
Frequently Asked Questions
Which credentials can the MEK-SW06 read?
It supports RFID, barcode, fingerprint and facial recognition, and communicates with access systems over TCP/IP or RS-485.
Can the turnstile be installed outdoors?
Yes. It is rated for indoor and outdoor use, with an operating temperature of -28°C to +60°C.
Is pricing available online?
Pricing depends on door size, configuration and accessories. Contact MEK Uganda for a quotation tailored to your opening.
To request a quotation or technical consultation, contact MEK Uganda at sales@mek.co.ug.
