Description
The MEK-SW300 is a heavy-duty operator for large single or double swing doors carrying up to 350 kg per leaf. A DC gear motor and spring return ensure reliable automatic closing, while anti-collision sensors, obstacle detection and an emergency stop button keep users safe. MEK Uganda supplies it for heavy entrance doors in commercial and industrial buildings.
Key Features
- Handles single or double leaf swing doors up to 350 kg per leaf
- DC drive gear motor with spring return for automatic closing
- Anti-collision sensors, obstacle detection and emergency stop button
- Microprocessor adjustment of speed, hold-open time and sensitivity
- Activation by motion sensors, push buttons or optional remote control
- High-strength, corrosion-resistant aluminium body
- Optional battery backup for power outages
Technical Specifications
- Type: Automatic swing door operator for single or double leaf doors
- Weight Capacity: Up to 350 kg per leaf
- Door Leaf Width: Up to 1500 mm (depending on door weight)
- Power Supply: 230V AC, 50/60Hz
- Power Consumption: Maximum 250W
- Operating Temperature: -20°C to +50°C
- Opening Speed: Adjustable from 3 to 7 seconds
- Closing Speed: Adjustable from 3 to 7 seconds
- Maximum Opening Angle: 90°
- Motor Type: DC drive gear motor
- Spring Return: Yes, for automatic closing
Applications
- Heavy entrance doors in commercial buildings
- Factories and industrial facilities
- Hospitals and public buildings with large swing doors
- Hotels and institutions with double-leaf entrances
Frequently Asked Questions
How heavy a door can the MEK-SW300 operate?
Up to 350 kg per leaf, with leaf widths up to 1500 mm depending on door weight.
Does the door close if power fails?
The operator has a spring return for automatic closing, and an optional battery backup keeps it working during a power outage.
Is pricing available online?
Pricing depends on door size, configuration and accessories. Contact MEK Uganda for a quotation tailored to your opening.
To request a quotation or technical consultation, contact MEK Uganda at sales@mek.co.ug.
